SWE 90UF

The Sunward SWE 90UF compact excavator was launched at the end of 2020. The SWE 90UF has been developed especially for a European market, where contractors, from demolition to rental market, will appreciate a compact machine that delivers heavy-duty performance. It features a very short-tail swing, making it the shortest 9-ton short-tail excavator (by almost 20 cm) available in the market.

Emission rating

Operating weight

Power output

Max. digging depth

Width

INTERESTED? CONTACT YOUR NEAREST DEALER
Share:

SUNWARD SWE 90UF

The Sunward SWE 90UF compact excavator was launched at the end of 2020. The SWE 90UF has been developed especially for a European market, where contractors, from demolition to rental market, will appreciate a compact machine that delivers heavy-duty performance. It features a very short-tail swing, making it the shortest 9-ton short-tail excavator (by almost 20 cm) available in the market. Thanks to its design, the SWE 90UF can offer great power at a reduced footprint, giving it the ability to fit into smaller spaces than other similar products.
It combines the power of the Yanmar 4TNV98C engine, delivering 46.2 kW, with incredible precision thanks to the dual proportional joysticks, the perfectly fitted hydraulic flow coupled with the LUDFF system (Load Independent Flow Control). To balance between fuel consumption and the desired productivity, the SWE 90UF offers 3 working modes.
Of course, because we know that safety and comfort should go hand-in-hand, the SWE 90UF keeps you safe and provides every comfort in all working conditions.
In the Sunward tradition to always offer the best value for money, the SWE 90UF is no exception since it offers many features and up to 5 years of warranty as standard, at the right price.
Discover all the other advantages of the Sunward SWE 90UF.

DIMENSIONS

Operating weight 8 750– 8 900 kg
Standard bucket capacity 0,26 m³
Shipping length 6 494 mm
Shipping width 2 250 mm
Height over cabin 2 735 mm

ENGINE

Model Yanmar 4TNV98C
Emission rating EU Stage V
Displacement 3.319 L
Rated power output 46.2 kW

HYDRAULIC SYSTEM

Type 1 variable piston pump
Displacement 160 L/min
Hydraulic pressure 28 Mpa

WORKING RANGE

Max. digging depth 4 545 mm
Max. digging reach 7 445 mm
Max. bucket digging force 63.5 kN
Max. arm digging force 38 kN

MADE FOR EUROPE

On top of its EU certification, the SWE 90UF has been developed specifically for the need of the European market.

POWERFUL & RELIABLE ENGINE

At the heart of the SWE 90UF, we chose the Yanmar 4TNV98C engine complying with the European Union’s latest Stage V emission requirements. This new generation engine features a common rail direct injection, assuring more precise fuel delivery and control, increased fuel economy, superior exhaust treatment, reduced emissions, and improved performances. In terms of power, Yanmar 4TNV98C offers an output of 46.2 kW, allowing powerful performance to meet a wide range of applications.

PREMIUM COMPONENTS

All key components in Sunward excavators are carefully selected, from Yanmar engine to hydraulics. Because hydraulics are often regarded as the heart of the machine, Sunward sources exclusively from the highest references in the market. Bosch Rexroth is the market leader in hydraulic pump innovation, design, and manufacture. So, it was natural for Sunward to select this premium brand to be our main pump supplier, as well as valves and joysticks. Our Bosch Rexroth hydraulic pumps deliver greater precision and reliability – which naturally reflects on the reliability of this machine. We also selected KYB or Flutek for the traveling and swing motors.

HIGH WORKING RANGE

The SWE 90UF has exceptional digging forces – 38 kN (arm) and almost 63.5 kN (bucket) – which is certainly equal to – and even better than – the 9-ton references available on the market. And when it comes to its long-reach digging capacity, the SWE 90UF is again very well positioned with its almost 7.5 m long reach.

HEAVYLIFTER

The SWE90UF has exceptional lifting capacities up to 4 749 kg (max.) and stretched reach up to 7 445 mm (max.) that easily rival the long-established 9-ton excavators on the market.

COMPACTNESS WITHIN A SHORT RADIUS

The SWE 90UF’s unique design augments the performance of its premium components, as this extremely compact 9-ton excavator is the shortest short-tail excavator (by almost 20 cm) available in the market. These precious centimeters of its swing radius make all the difference between being transported on a regular truck rather than a specialized one. Then, on the job, the SWE 90UF provides the stability required for long-reach digging and heavy-lifting duty.

WELL-EQUIPPED FROM THE OUTSET

This slightly Sunward SWE 90UF mini excavator has it all from the day it leaves the factory:
– Auto idle engine to save fuel and limit the engine’s consumption. – While other manufacturers usually use a flow throttle (because it’s cheaper), we at Sunward opt for a Load Sensing (hydraulic) system, which provides better energy saving possibilities.
– Safety valves for the boom cylinder for safer operations.
– Auto-shifting traveling motor for smooth operations to the operator.
– TOPS, FOPS & ROPS cab.
– Battery cut-off switch for safer operations and prolonged battery lifetime and power – which is especially appreciated in the cold weather of Scandinavian countries.
– Double Acting Hydraulic Circuit
– Factory-fitted Hydraulic Quick Hitch Lines
– Factory-fitted Hammer & Rotation Line
– Factory-fitted Case Drain Line
– Factory-fitted Dual Proportional Joysticks
– Factory-fitted Tiltrotator Configured Joystick Controls (tiltrotator of your choice)
– 4 LED work lights as standard: 2 on the front of the cab, and 2 on both sides of the boom

EASY TO MAINTAIN

To reduce maintenance time and cost for the SWE 90UF, the covers at the rear and on the side provide direct access to the service points. The standard service points – for fuel, oil, and air filters – are directly accessed via the cover at the rear. So, with very easy access to the fuel tank and centralized grease fittings, these mini excavators are as easy to maintain as they are to operate.

SAFE CAB

The high‑strength SWE 90UF cab meets no less than FOPS, TOPS, and ROPS requirements, which are standard and among the first features to ensure a safe and comfortable job in all application environments. Despite its compact size from the outside, the SWE 90UF offers easy access to the roomy cab, welcoming operators of all sizes from everywhere in Europe. Thanks to the large windows and the well‑organized cab, everything is designed to keep operators comfortable and productive as well as safe.

BEST VALUE FOR MONEY

Sunward is your smartest investment in reliability, performance, and high ROI. Indeed, the SWE 90UF’s expert design includes a well-thought-out selection of components that streamline operation and maintenance. Our design choices result in a machine that provides so many standard features, premium-brand key components, and capabilities at the right price.
And furthermore, Sunward’s own genuine spare parts are economical as well – and all of this best value for money is crowned by up to 5 years of warranty, standard for all Sunward products.
