SWE 25UF

SWE25UF MAINSWE25UF MAIN

SWE 25UF

The Sunward SWE 25UF mini excavator is the zero-tail version of the SWE 25F mini excavators. As the SWE 25F, the SWE 25UF benefits from exceptionally good performance on the job. But its unique zero-tail compact design makes it the perfect option for tight jobsites where power is required. Its weight category makes it very easy to transport.

Emission rating

Operating weight

Power output

Max. digging depth

Width

INTERESTED? CONTACT YOUR NEAREST DEALER
Share:

SUNWARD SWE 25UF

The Sunward SWE 25UF mini excavator is the zero-tail version of the SWE 25F mini excavators. As the SWE 25F, the SWE 25UF benefits from exceptionally good performance on the job. But its unique zero-tail compact design makes it the perfect option for tight jobsites where power is required. Its weight category makes it very easy to transport. In the Sunward tradition to always offer the best value for money, the SWE 25UF is no exception since it offers many features and up to 3 years of warranty as standard, at the right price. Of course, because we know that safety and comfort should go hand-in-hand, the SWE 25UF keeps you safe and provides every comfort in all working conditions.
Discover all the other advantages of the Sunward SWE 25UF.

TYPE OF CAB

Type of cab Cab or Canopy

DIMENSIONS

Operating weight 2 550 – 2 650 kg
Standard bucket capacity 0,08 m³
Shipping length 4 262 mm
Shipping width 1 500 mm
Height over cabin 2 455 mm

ENGINE

Model Yanmar  3TNV80F-SPSU
Emission rating EU Stage V
Displacement 1.267 L
Rated power output 14.6 kW

HYDRAULIC SYSTEM

Type 1 variable piston pump
Displacement 77 L/min
Hydraulic pressure 24.5 Mpa

WORKING RANGE

Max. digging depth 2 840 mm
Max. digging reach 4 775 mm
Max. bucket digging force 24 kN
Max. arm digging force 14 kN

MADE FOR EUROPE

On top of its EU certification, the Sunward SWE 25UF, like all Sunward machines on the European market, is designed to meet European customer needs.

POWERFUL & RELIABLE ENGINE

We chose the powerful Yanmar 3TNV80F-SPSU engine featuring low fuel consumption, low noise and vibration levels, and high-altitude performance control, ensuring intensive work in a severe environment. This 14.6 kW industrial diesel engine is both EPA Final Tier 4 and EU Stage V compliant, and its compact design means it can fulfill a variety of roles. The Yanmar engine perfectly matches with the power of the hydraulic system, guarantying smooth operation. This engine is the perfect fit for our reliable and versatile Sunward SWE 25UF.

PREMIUM COMPONENTS

All key components in Sunward excavators are carefully selected, from Yanmar engine to hydraulics. Because hydraulics are often regarded as the heart of the machine, Sunward sources exclusively from the highest references in the market. For our Sunward SWE 25UF, we selected Japanese premium brands to be our main suppliers for the hydraulic pump, traveling and swing motor. NACHI and Kayaba pumps and components are efficient, reliable, and space-saving. So, it’s no coincidence that Sunward selected them to contribute to the SWE 25UF’s reliability.

HIGH WORKING RANGE

The SWE 25UF has exceptional digging forces of 24 kN (bucket) and 14 kN (arm), which easily rival the 2.5-ton excavator competitors on the market. And when it comes to its long-reach digging capacity, the SWE 25UF’s boom cylinder design provides a maximum reach of over 4.7 meters (4 775 mm) long.

READY FOR A VARIETY OF APPLICATIONS

A mini-excavator’s versatility starts with how well it is designed for transportation. The SWE 25UF does more than simply align with the EU’s transportation regulations – truly compact (1 500 mm width) and lightweight (2 550 – 2 650 kg), it allows easy, safe, and secure transport. With an automatic slew lock and 4 easily accessed tiedown points on the undercarriage, the machine can be safely transported on a small trailer with up to 3 buckets and a hydraulic breaker. The SWE 25UF can adapt to any job site, thanks to the complete auxiliary settings built-in as standard – providing fully adjustable pressure and flow monitoring. This results in no less than 3 separate auxiliary lines as standard (while the market provides 1 to 2 lines as standard). Thus, a wide range of attachments can be easily fitted to answer a variety of applications.

WELL-EQUIPPED FROM THE OUTSET

The Sunward SWE 25F is very well equipped from the day it leaves the factory:
– Double Acting Hydraulic Circuit
– Factory-fitted Hydraulic Quick Hitch Lines
– Factory-fitted Hammer & Rotation Line
– Factory-fitted Case Drain Line
– Factory-fitted One hydraulic pilot control with a double contact switch
– Factory-fitted Tiltrotator Configured Joystick Controls (tiltrotator of your choice)
– 3 LED work lights as standard: 2 on the front of the cab, 1 on the left side of the boom

EASY TO MAINTAIN

On the Sunward 25UF, the service points have been centralized to make it easy to maintain and service. To reduce maintenance time and cost, the cover at the rear provides direct access to the service points. With very easy access to the fuel tank and centralized grease fittings, the SWE 25UF is as easy to maintain as it is to operate.

BEST VALUE FOR MONEY

Sunward is your smartest investment in reliability, performance, and high ROI. Indeed, the SWE 25UF’s expert design includes a well-thought-out selection of components that streamline operation and maintenance. Our design choices result in a machine that provides so many standard features, premium-brand key components, and capabilities at the right price.
And furthermore, Sunward’s own genuine spare parts are economical as well – and all of this best value for money is crowned by up to 3 years of warranty, standard for all Sunward products.

Product brochure
