SL 06W
The SL 06W from Sunward is a noteworthy addition to the compact wheel loader market, featuring a range of beneficial attributes.
It is powered by a Yanmar engine that efficiently balances robust performance with environmental responsibility.
| Rated load | 600 kg |
|---|---|
| Operating weight | |
| Power output | |
| Bucket capacity | 0.26 m³ |
SUNWARD SL 06W
The SL 06W from Sunward is a noteworthy addition to the compact wheel loader market, featuring a range of beneficial attributes.
It is powered by a Yanmar engine that efficiently balances robust performance with environmental responsibility.
With an operating weight of 1,700 kg and a thoughtfully designed bucket, this loader offers stability and efficiency for diverse tasks.
Designed with versatility in mind, the SL 06W addresses the demands of various applications, from construction to agriculture. Its compact size and enhanced manoeuvrability make it a practical choice in settings where space is limited.
Additionally, the loader’s EU Stage V engine is engineered to produce low emissions, aligning with Sunward’s focus on eco-friendliness and operational cost-effectiveness.
DIMENSIONS & WEIGHT
| Operating weight | 1 700 kg |
| Length with standard bucket | 3 669 mm |
| Width without bucket | 1 120 mm |
| Height to top of ROPS | 2 310 mm |
ENGINE
| Model | YANMAR 3TNV88 |
| Emission rating | EU Stage V |
| Rated power output | 18.2 kW |
PERFORMANCE
| Rated operating capacity | 1 700 kg |
| Tipping load | 600 kg |
| Bucket capacity | 0.26 m³ |
| Max. breakout force | 13 kN |
| Travel speed | 12 km/h |
MADE FOR EUROPE
Like all the Sunward machines on the European market, the SL 06W is designed to meet European customer needs and has all the EU certifications.
BUILT FOR MULTITASKING
Made to be flexible, the SL 06W can handle the demands of various applications, from construction to agriculture. It’s compact and maneuverable, making it ideal for tight spaces.
A skid-steer versatility starts with how well it is designed for transportation. The SWL 4038 does more than simply align with the EU’s transportation regulations – truly compact (1 120 mm width) and lightweight (1 700 kg), its small frame allows easy, safe, and secure transport behind a pickup truck.
RELIABLE PERFORMANCE
Despite its compact size, the SL 06W has impressive breakout force, huge lift capacity, and fast cycle times.
The powerful YANMAR 3TNV88 engine delivers a power of 18.2 kW (@2 200 rpm) and offers exceptional reliability even in severe, high load conditions, long service life and complies with the European Union’s Stage V emission requirements.
COMFORT AS STANDARD
The comfort of the Sunward SL 06W starts with easy cab access. Once seated, the SL 06W offers a spacious cab, air conditioning, a comfortable seat, and ergonomic controls for maximum operating comfort.
SERVICE MADE EASY
Because we care about your operative costs, maintenance and service have been made easy. Daily preventive maintenance is very simple since service checkpoints and cooling system components are accessible at ground level from the rear door. When it comes to service, major components are also easily and quickly accessible by tilting the ROPS/FOPS cab.
SAFETY IS NOT AN OPTION
Safety is and will always be a priority for Sunward. The SL 06W has been designed for operator safety.
Thus, the ROPS/FOPS cab and rear window exit coupled with the excellent visibility and great stability of the machine guarantee maximum safety.
A seat switch and armbar switch also prevent the machine from being started without an operator present.
In terms of systems, the SL 06W skid steer has been equipped with an emergency descent function, so that the boom can safely conduct the emergency descent n the event of an unexpected engine shut down.
