SWE 20F
The Sunward SWE 20F features a redesigned, more spacious cab for enhanced comfort and control. Compact, powerful, and easy to transport, it delivers reliable performance, stability, and operator safety in all working conditions.
| Emission rating | |
|---|---|
| Operating weight | |
| Power output | |
| Max. digging depth | |
| Width |
SUNWARD SWE 20F
The Sunward SWE 20F is a next-generation 2-ton mini excavator designed to deliver enhanced comfort, performance, and efficiency on every jobsite. Built to meet the demands of modern applications, it combines a compact design with advanced features to support productivity in a wide range of tasks.
A completely redesigned, more spacious cab provides improved visibility, reduced noise levels, and a more comfortable working environment. The upgraded suspension seat and modern digital display further enhance operator experience, making long working hours more efficient and less demanding.
The SWE 20F remains easy to transport and fully compliant with EU requirements. Its extendable undercarriage (from 990 mm to 1,320 mm) ensures excellent stability, allowing the machine to perform confidently even on uneven or challenging terrain.
In line with Sunward’s philosophy of delivering maximum value for money, the SWE 20F comes well-equipped as standard, offering a high level of functionality without compromise.
Designed with practicality in mind, the machine provides easy access for maintenance, along with compatibility with a wide range of attachments to suit different applications. Whether used in landscaping, urban construction, or utility work, the SWE 20F delivers precision, reliability, and operator comfort in every task.
Discover more about the SWE 20F.
TYPE OF CAB
| Type of cab | Cab or Canopy |
DIMENSIONS
| Operating weight | 1 910 kg |
| Standard bucket capacity | 0.035 m³ |
| Shipping length | 3 840 mm |
| Shipping width | 990 mm |
| Height over cabin | 2 360 mm |
ENGINE
| Model | Yanmar 3TNV80F-SSU |
| Emission rating | EU Stage V |
| Displacement | 1.267 L |
| Rated power output | 13.4 kW |
HYDRAULIC SYSTEM
| Type | 2 variable piston pumps + 1 gear pump + 1 pilot gear pump |
| Displacement | 2*21+13+6 L/min |
| Hydraulic pressure | 21 / 19 Mpa |
WORKING RANGE
| Max. digging depth | 2 260 mm |
| Max. digging reach | 4 075 mm |
| Max. bucket digging force | 21 kN |
| Max. arm digging force | 9.8 kN |
MADE FOR EUROPE
On top of its EU certification, the Sunward SWE 20F, like all Sunward machines on the European market, is designed to meet European customer needs.
POWERFUL & RELIABLE ENGINE
We chose the powerful Yanmar 3TNV80F-SSU engine for the new SWE 20F, known for its low fuel consumption, quiet operation, and consistent performance – even in high-altitude or demanding environments. Delivering 13.4 kW, this compact industrial diesel engine meets both EU Stage V and EPA Final Tier 4 standards. Perfectly matched with Sunward’s advanced hydraulic system, it ensures smooth, responsive operation across all applications – making it the ideal power unit for this next-generation, high-performance mini excavator.
PREMIUM COMPONENTS
All key components in the new Sunward SWE 20F are carefully selected to ensure maximum performance and durability – from the trusted engine to the high-efficiency hydraulic system. Since hydraulics are the heart of any excavator, Sunward relies on premium manufacturers for the hydraulic pump, swing motor, and travel motor. Known for their compact design, reliability, and efficiency, these components provide smooth, responsive control and play a crucial role in the SWE 20F’s exceptional performance and long-term dependability.
FLEXIBLE AND STABLE
The SWE20F’s extendable undercarriage – the track width can be extended from 990 mm to 1360 mm – provides sturdy stability, ensuring safe and comfortable operation in all kinds of job applications. The adjustable crawler track is ideal in confined areas or when greater stability is required.
HIGH WORKING RANGE
The SWE 20F delivers exceptional digging forces – over 21 kN on the bucket and 9.8 kN on the arm – placing it among the top performers in the 2-ton class. Its optimized boom and arm geometry, paired with a cylinder design focused on reach and efficiency, offers a maximum digging reach of over 3.8 meters and a digging depth of more than 2 meters, giving operators outstanding range and precision on any jobsite.
READY FOR A VARIETY OF APPLICATIONS
A mini excavator’s versatility begins with how easily it can be transported – and the new SWE 20F goes beyond EU transport compliance. With a compact width of just 990 mm and a transport weight starting at 1 910 kg, it’s ideal for loading on a small trailer along with up to 3 buckets and a hydraulic breaker, keeping the total transport weight close to 2 tons. Equipped with an automatic slew lock and 4 easily accessible tie-down points integrated into the undercarriage, it ensures safe and secure transit. On site, the SWE 20F adapts effortlessly to multiple tasks, thanks to 3 auxiliary hydraulic lines as standard – a rare feature in this class—complete with adjustable pressure and flow settings. This makes it compatible with a wide range of attachments, from breakers and augers to tilt buckets and grapples, right out of the factory.
BEST VALUE FOR MONEY
Sunward is your smartest investment in reliability, performance and high ROI. Indeed, the SWE 20F’s expert design includes a well-thought-out selection of components that streamline operation and maintenance. Our design choices result in a machine that provides so many standard features, premium-brand key components, and capabilities at the right price.
And furthermore, Sunward’s own genuine spare parts are economical as well – and all of this best value for money is crowned by up to 5 years of warranty, standard for all Sunward products.
