SWE 08F
Unveiling at INTERMAT 2024 in Paris, the Sunward SWE 08F micro excavator is a testament to the brand’s dedication to continuous improvement and customer-focused design. As the latest iteration based on the widely acclaimed SWE 08B, the SWE 08F marks a significant evolution, joining the esteemed ranks of Sunward’s F Series.
| Emission rating | |
|---|---|
| Operating weight | |
| Power output | |
| Max. digging depth | |
| Width |
SUNWARD SWE 08F
Sunward’s SWE 08F micro excavator, unveiled at INTERMAT 2024, is an evolution of the SWE 08B, enhanced by European customer feedback. Retaining its Yanmar engine, the SWE 08F maintains key specs while offering structural and ergonomic upgrades for better stability and operator comfort. This new model features advanced hydraulic components for improved manoeuvrability and a 16% increase in breaking capability. It epitomizes Sunward’s commitment to innovation, setting a new standard in the micro excavator segment for diverse construction needs.
DIMENSIONS
| Operating weight | 1 010 kg |
| Standard bucket capacity | 0,022 m³ |
| Shipping length | 2 640 mm |
| Shipping width | 750 mm |
| Height over cabin/canopy | 2 276 mm |
ENGINE
| Model | Yanmar 2TNV70-PSU |
| Emission rating | EU Stage V |
| Displacement | 0.57 L |
| Rated power output | 7.2 kW |
HYDRAULIC SYSTEM
| Type | 3 Coupling Gear Pumps |
| Displacement | 2*9.6 L/min |
| Hydraulic pressure | 16 Mpa |
WORKING RANGE
| Max. digging depth | 1 446 mm |
| Max. digging reach | / |
| Max. bucket digging force | 9.4 kN |
| Max. arm digging force | 5.8 kN |
MADE FOR EUROPE
On top of its EU certification, the Sunward SWE 08F, like all Sunward machines on the European market, is designed to meet European customer needs.
POWERFUL & RELIABLE ENGINE
We chose the powerful Yanmar 2TNV70-PSU engine featuring low fuel consumption, low noise and vibration levels, and high-altitude performance control. This 7.2 kW industrial diesel engine is both EPA Final Tier 4 and EU Stage V compliant, and its compact design means it can fulfill a variety of roles. The perfect fit for our reliable and versatile Sunward SWE 08F.
PREMIUM COMPONENTS
All key components in Sunward excavators are carefully selected, from Yanmar engin to hydraulics. Because the hydraulics are often regarded as the heart of the machine, Sunward sources exclusively from the highest references in the market. For our Sunward SWE 08F, we selected Japanese premium brands to be our main suppliers for the hydraulic pump, traveling and swing motor. NACHI and Kayaba pumps and components are efficient, reliable, and space-saving. So, it’s no coincidence that Sunward selected them to contribute to the SWE 08F’s reliability.
COMPACT DESIGN
The SWE 08F is meticulously engineered to cater to varied construction scenarios, whether indoor or outdoor. It retains the practical features that made the SWE 08B a favourite, such as track extension, boom swing, and upper structure rotation, complemented by a folding dozer blade for versatility.
HIGH WORKING RANGE
Despite its very compact size, the SWE 08F has powerful lifting & digging forces and long reach capacity. The SWE 08F has exceptional digging forces of over 9,4 kN (bucket) and almost 5,8 kN (arm). And when it comes to its long-reach digging capacity, the SWE 08F boom cylinder design provides a reach of 750 mm long.
READY FOR A VARIETY OF APPLICATIONS
A mini-excavator’s versality starts with how well it is designed for transportation. The SWE 08F does more than simply align with the EU’s transportation regulations – truly compact (750 mm width, but can be extended to 1000 mm) and lightweight (1010 kg), it allows easy, safe and secure transport. A wide range of attachements can be easily fitted to answer a variety of applications.
BEST VALUE FOR MONEY
Sunward is your smartest investment in reliability, performance and high ROI. Indeed, the SWE 08F’s expert design includes a well-thought-out selection of components that streamline operation and maintenance. Our design choices result in a machine that provides so many standard features, premium-brand key components, and capabilities at the right price.
And furthermore, Sunward’s own genuine spare parts are economical as well – and all of this best value for money is crowned by up to 5 years of warranty, standard for all Sunward products.
